1600
kg
Lifting Capacity
4600
mm
Lifting Height
24/280
V/Ah
Battery Capacity
1.5 AC
kW
Travel Motor
3 DC
kW
Lifting Motor
6
Hours
Continuous Operation
|
H4 |
Lift Open Height |
5100 mm |
|
H3 |
Lifting Height |
4600 mm |
|
H2 |
Free Lifting |
100 mm |
|
H1 |
Lift Closed Height |
2100 mm |
|
I1 |
Overall Length |
1984 mm |
|
I |
Fork Length |
1150 mm |
|
Q |
Lifting Capacity |
1600 kg |
|
X |
Distance between Axle and Body |
783 mm |
|
S |
Fork Thickness |
60 mm |
|
M |
Minimum Ground Clearance |
26 mm |
|
H14 |
Total Height with Arm |
870/1200 mm |
|
H13 |
Minimum Fork Height |
86 mm |
|
I1 |
Overall Length |
2020 mm |
|
Y |
Axle Distance |
1384 mm |
|
C |
Load Centre |
600 mm |
|
B1 |
Width Dimension |
1050 mm |
|
B10 |
Drive Wheel and Balance Wheel Axle |
526 mm |
|
B11 |
Distance Between Forks |
207 mm |
|
B5 |
Fork Width |
570 mm |
|
AST |
Aisle Width for 1000x1200 Size Pallet |
2458 mm |
|
AST |
Aisle Width for 800x1200 Size Pallet |
2398 mm |
|
WA |
Minimum Rotation Angle |
1620 mm |
|
E |
Fork Dimensions |
180 mm |
|
N |
Weight |
1410 kg |
| Movement Speed Loaded/Unloaded | 5.2/5.5 | km/h |
| Lifting Speed Loaded/Unloaded | 70/110 | mm/s |
| Download Speed Loaded/Unloaded | 95/100 | mm/s |
| Maximum Slope Loaded/Unloaded | 6/8 | % |
PRODUCT
FEATURES
- Wide and Balanced Body
- AC Walking Motor
- High Capacity Traction Battery
- Impact Resistant Professional Chassis
- Heavy Duty Fork Structure
- Operator Platform
- AC Walking Motor
- High Capacity Traction Battery
- Impact Resistant Professional Chassis
- Heavy Duty Fork Structure
- Operator Platform
1600 KG CARRYING CAPACITY
MAXIMUM HEIGHT 800 KG
4600 MM LIFTING HEIGHT
MAXIMUM TRANSPORT HEIGHT 250 MM
AMERICAN CURTIS CONTROL CARD
TRACTION BATTERY
UNMAINTAINED AC MOTOR
POSSIBILITY TO WORK ON SHELVES IN NARROW SPACE
LIMIT LIQUID AT FINAL HEIGHT
H TYPE TENSILE STEEL MAST
SLOW WALKING MODE
WALK-BACK SAFETY TO PROTECT THE OPERATOR
SUITABLE FOR EURO PALLET
